224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯带发电用打着机汽油划算性好: 高级的汽油管理机体统，独到的STC、ESTC 等级分类管理机体统，特别的设计的概念的连杆顶上一氧化碳引燃仓，高压力喷出汽油，加以吸雾，一氧化碳引燃加以。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯发电量用启驱力瞬态功能非常好: 好看的启驱力整体布局制作，配合默契康明斯独一无二的EFC系统软件，把控好计算精度更高，加载时间段快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯生产发电用发起机升瓦数高: 全局设计制作紧身.看上去摆设合理有效，行驶能保持稳定。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷款型 QSNT. QSK19. QSK38. QSK50做到中国有非旅程其三的时候及亚洲Tier2. Tier 3排放出法律法规规定要求。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零备品备件都有机会得到性好， 热车机执行及运营维护定期维护连锁便利店，总损坏后可及时更换。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

工率依据 Power Range   224-310KW类型 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L外型尺寸大小 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净效果 Dry Weight   940kg

224-310KW康明斯来发电用启思想的共同点：大小小， 收缩变高， 除雾器的空气煮沸，便于进行，转动车载多媒体24v电源的首先选择。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

起心理规格	惯用效率(kW)Prime Power	备用电源马力kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
